Automatic Programming Software 380V 5kw EPS PU Foam Cutting Machine
automatic programming software 380V 5KW eps pu foam cutting machine Product Description Application area: This foam cutt
Send your inquiryDESCRIPTION
Basic Info.
| Model NO. | BPQ |
| Condition | New |
| Height of The Foam Block | 1250mm |
| MOQ | 1 |
| Max Cutting Speed | 15m/Minute |
| Power(W) | 5kw |
| Applicable Industries | Manufacturing Plant |
| Weight | Choose |
| Voltage | AC 380V |
| After-Sales Service Provided | Video Technical Support, Free Spare Parts |
| Cutting Precision | ±0.5mm |
| Width of The Foam Block | 2200mm |
| Length of The Foam Block | 2200mm |
| Pressure of The Knife | 6 Bar |
| Transport Package | Wooden Case |
| Trademark | BCD |
| Origin | Jiangsu, China |
Product Description
automatic programming software 380V 5KW eps pu foam cutting machine
Product Description
Application area: This foam cutter machine can cleanly cutting any ideal geometric profile. It can be used in Automotive industry, Furniture industry, Packing industry, Building industry, Daily commodity and so on.Cutting material: Foam,PU soft foam,sticky foam,latex,Rebond foam, Polyethylene foam. Performance overview:The automation of this equipment is highly , it is able to complete some of the basic cutting requirements,The Rotate worktable can rotate without limit . Cutting graphics: It is suitable for cutting block product ;it can cutting Pyramid-shaped with the rotate worktable;wavilness;irregular shape ;and any two dimensions and the simple three dimensions geometric profile . It can cleanly cutting any ideal geometric profile. It can be used in Automotive industry, Furniture industry, Packing industry, Building industry, Daily commodity and so on.
| Length of the foam block | 2200mm | 2300mm |
| Height of the foam block | 1250mm | 1500mm |
| Width of the foam block | 2200mm | 2300mm |
| Work table | Rotating work table | |
| AC power | 380V 3phase 4 wire | |
| Total power | 5KW | |
| Cutting precision | ±0.5mm | |
| Cutlery | -Pressure of the knife is 6 bar -Itinery of the knife is 48mm50Hz -Size of the knife is 0.5mm*3mm*2300mm -Vibrating speed is 3000t/minute | |
| Operatiing option | -modulator demodulator(can do remote diagnosis and maintenance) -man controlled rotating work table -automatic programming software -computer console -Absolute value of the system - Automatic adjusting the angle -Hanging control panel (optional) | |
| Max cutting speed | Depending on different materials, the max cutting speed is 15m/minute | |
| Delivery date | 25Days After receipt of prepayment. | |
Classification
Company Information
Certifications
Contact Us
FAQ
Q. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance. Other payment terms can also be negotiated.
Q. What is your terms of delivery?
A: EXW, FOB, CFR, CIF.
Q. How about your delivery time?
A: Generally, it will take 20 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q. Do you test all your machines before delivery?
A: Yes, we have 100% test before delivery.
Q. Do you have some videos where we can see the line producing?
A: Yes, we can provide some videos for reference.
Q: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
